China successfully retrieved experimental building materials designed for lunar construction last week, marking a critical milestone in its race to establish the first permanent moon base.
The brick samples, made from simulated lunar soil, returned to Earth aboard the Shenzhou-21 spacecraft after enduring a full year of exposure to the harsh space environment outside the Tiangong space station.
Initial inspections confirmed the samples remained in good condition, validating the feasibility of using local lunar materials for future construction projects.
The achievement propels China's ambitious timeline forward, keeping the nation on track to land astronauts on the moon by 2030 and construct a basic model of the International Lunar Research Station by 2035.
With 17 countries and over 50 international research institutions now participating in the project as of April 2025, the successful brick experiment demonstrates that building permanent structures using moon resources is no longer science fiction but an engineering reality within reach.
How Did the Lunar Bricks Survive a Year in Space
The experiment began in November 2024 when the Tianzhou-8 cargo ship delivered 74 small brick samples to China's Tiangong space station, according to research led by Ding Lieyun, a scientist at Huazhong University of Science and Technology.
Unlike typical spacecraft cargo, which remains protected inside pressurized modules, these samples were deliberately mounted on an external exposure platform, where they faced the full brutality of the space environment.
The bricks endured cosmic radiation levels far exceeding those on Earth, continuous ultraviolet bombardment from unfiltered sunlight, and temperature swings ranging from minus 190 degrees Celsius in shadow to 180 degrees Celsius in direct sunlight.
These extreme conditions closely simulate what construction materials would face on the lunar surface, where there is no atmosphere to moderate temperature or filter radiation.
The samples' successful survival for 12 months provides critical data on material degradation rates and structural integrity under prolonged space exposure.
Scientists will now examine microscopic changes in the brick structure, measuring any weakening of molecular bonds, surface erosion from micrometeorite impacts, and thermal-stress fractures that could compromise long-term building safety.
Did you know?
The lunar brick design draws inspiration from traditional Chinese mortise and tenon joinery, allowing interlocking construction without binding agents, a technique used in ancient Chinese architecture for over 7,000 years.
What Makes These Bricks Stronger Than Traditional Materials
The lunar bricks developed by Ding's team exhibit remarkable strength, surpassing that of conventional construction materials used on Earth.
Each square centimeter can support over 1 ton, giving them more than 3 times the compressive strength of standard building bricks while maintaining comparable density.
This exceptional strength-to-weight ratio makes them ideal for lunar construction, where every kilogram of material transported from Earth costs thousands of dollars in rocket fuel and mission complexity.
The bricks achieve their superior properties through a hot-press sintering process that fuses particles at high temperatures, without requiring water or chemical binding agents, both of which are scarce on the moon.
Drawing inspiration from traditional Chinese masonry techniques, the team designed interlocking mortise-and-tenon joints that mechanically connect bricks, eliminating the need for mortar or adhesives.
This ingenious design approach means lunar habitats could be assembled like giant puzzle pieces, with each brick locking securely to its neighbors through precisely engineered protrusions and recesses.
Why Is China Using Volcanic Ash From Changbai Mountain
Scientists developed the test bricks by first analyzing authentic lunar specimens returned by China's Chang'e-5 mission in December 2020, which collected 1,731 grams of material from the Moon's surface.
This analysis revealed the precise chemical fingerprint and mineral composition of actual lunar regolith, providing the blueprint for creating accurate simulants.
Rather than attempting to synthesize compounds in a laboratory, the research team searched for terrestrial materials that matched the lunar composition profile.
Volcanic ash from Changbai Mountain in northeast China's Jilin Province emerged as the ideal candidate, closely matching the elemental composition and particle-size distribution of lunar regolith.
The volcanic origin of this material makes sense, given that much of the Moon's surface consists of ancient volcanic plains and impact-melt deposits with a similar mineralogy.
Using this naturally occurring simulant allows researchers to conduct extensive testing and refinement of brick manufacturing processes at a fraction of the cost of working with precious, authentic lunar samples.
ALSO READ | Google Releases Free Antigravity IDE for Developer Workflows
What Comes Next in the Three-Year Testing Timeline
The current experiment represents only the first phase of a comprehensive three-year study designed to evaluate long-term material performance in the space environment.
Additional sample batches will return to Earth after two years and three years of exposure, allowing scientists to map degradation curves and predict how the bricks will hold up over decades of use in a permanent lunar base.
Each returning batch will undergo detailed analysis, including electron microscopy to examine surface changes, spectroscopy to detect chemical alterations, and mechanical stress testing to measure any loss of structural integrity.
China's space agency confirmed on October 30, 2025, that all components of the crewed lunar mission program are progressing smoothly, with the Long March 10 rocket and Mengzhou spacecraft completing prototype development and testing as planned.
Thermal evaluations of the Lanyue lunar lander, which will transport crew members from orbit to the moon's surface, have already been completed.
The comprehensive testing schedule includes integrated system assessments, maximum dynamic-pressure escape tests for crew safety, and low-altitude verification flights, all of which build toward the historic 2030 crewed landing.
How Will Chang'e-8 Test Construction on the Actual Moon
China's Chang'e-8 mission, scheduled to launch around 2028, will carry revolutionary technology to demonstrate brick production using actual lunar regolith rather than Earth-based simulants.
The mission will deploy a solar-powered robotic system capable of 3D printing construction materials directly on the lunar surface, eliminating the need to transport pre-made building components from Earth.
Wu Weiren, chief designer for the Chinese Lunar Exploration Program, explained that the system concentrates sunlight to achieve temperatures between 1,400 and 1,500 degrees Celsius, hot enough to melt lunar soil and shape it into bricks of various specifications.
This approach, known as in-situ resource utilization, could dramatically reduce the costs of lunar construction by using materials already present on the moon rather than launching every component from Earth at enormous expense.
The Chang'e-8 robot will test fiber-optic technology to transmit concentrated solar energy to processing equipment, proving that construction can proceed using only sunlight and moon dust, without requiring water, chemical binders, or other Earth-supplied materials.
Success would validate the core technology needed to build the International Lunar Research Station, transforming humanity's relationship with the moon from brief visits to permanent habitation.
As space agencies worldwide race to establish lunar infrastructure, China's methodical testing program positions the nation at the forefront of practical moon base technology.
The successful retrieval of the first brick samples proves that materials science developed on Earth can withstand the unforgiving lunar environment.
At the same time, upcoming missions will demonstrate that autonomous construction systems can operate reliably 384,400 kilometers from human oversight.
With each successful test, the vision of scientists working year-round in lunar laboratories moves closer to reality, potentially unlocking discoveries that would be impossible to achieve during short-term missions.
