Johns Hopkins Pioneers Technique for Ultra-Small, Cost-Effective Microchips

Johns Hopkins scientists have pioneered a new technique with metals and light-sensitive chemistry that makes microchips smaller, faster, and more economical.

AvatarJR

By Jace Reed

3 min read

Image Credit: Tony Webster / Wikimedia Commons
Image Credit: Tony Webster / Wikimedia Commons

Scientists at Johns Hopkins University have pioneered a method that enables the creation of microchips so small and precise they border on invisibility. By leveraging metals and light-sensitive chemistry, their approach stands to transform industries from consumer electronics to commercial aerospace.

This research removes obstacles from traditional manufacturing processes, paving the way for faster and more affordable chips.

Their findings were recently published in Nature Chemical Engineering, offering key lessons for next-generation device fabrication.

What Is the New Technique Developed by Johns Hopkins?

The technique revolves around the use of metal-organic materials paired with a chemical process called chemical liquid deposition (CLD). This allows researchers to coat silicon wafers with nanometer precision using solutions rather than complex mechanical processes.

The innovation enables mass production while sharply lowering manufacturing costs.

By precisely controlling the layer thickness and material composition, scientists demonstrated a simple and scalable approach for designing circuitry too small to see unaided, helping satisfy industry demand for smaller, more powerful chips.

Did you know?
Zinc, one of the metals used in the new chemistry, performs poorly for standard EUV but excels with B-EUV, opening unexpected paths for next-gen chips.

How Does Metal-Organic Chemistry Enable Smaller Chips?

Traditional “resist” materials struggle to react to the higher-powered radiation required for fine chip features. The Johns Hopkins team discovered that metal-organic resists can take in strong light and start reactions that are useful for creating very tiny circuit patterns on silicon wafers.

Metals like zinc, combined with an organic molecule called imidazole, captured the new light wavelength with exceptional efficiency.

With more than ten different metals available and hundreds of organic combinations possible, the technique opens up rapid experimentation to unlock optimal material pairings for future microchip production.

What Are the Advantages of Chemical Liquid Deposition?

CLD offers a simple route for applying resists with high uniformity, directly from solution and at large scales. This flexibility allows manufacturers to quickly adjust chip designs, improve reliability, and minimize waste compared to conventional manufacturing.

Additionally, the technique is poised to boost compatibility with powerful industrial equipment already used for commercial chip etching, supporting rapid rollout of new microchip generations.

ALSO READ | IonQ’s Breakthrough Paves Way for Quantum Internet Using Telecom Fibers

Why Is Beyond Extreme Ultraviolet Light Important?

Microchip miniaturization relies on radiation that carves ever-tinier patterns into silicon. Beyond extreme ultraviolet (B-EUV) light interacts powerfully with tailored metal-organic resists, letting features shrink below current industry minimums of 10 nanometers.

Zinc, for instance, works poorly with standard EUV light but is highly effective for B-EUV wavelengths, enabling new stages of fabrication.

The interplay of light and chemistry drives near-instant reactions, ensuring high-speed, high-precision manufacturing that keeps pace with semiconductor roadmaps for the next decade.

What Could This Breakthrough Mean for Future Electronics?

The Johns Hopkins breakthrough could usher in a new era for all electronic systems. Ultra-small chips will drive faster smartphones, smarter appliances, and advanced control systems for cars and aircraft.

The scalable, cost-efficient process may help democratize next-gen chips, making powerful devices more widely available.

Industry researchers have begun experimenting with pairings for B-EUV manufacturing, with commercial rollout likely in the next ten years.

The move to metal-organic chemistry and CLD is expected to spur radical advances in computing, connectivity, and device design.

With this chemistry leap, manufacturers now possess a versatile toolbox for rapid innovation.

As the technology matures, expect waves of new applications, smarter gadgets, and surprising solutions all powered by invisible but mighty microchips.
